EBR front reinforcement / mudguard arch black | Puch Maxi / EX30 Velux

swiing® revival cable guide mudguard black | Puch

Height: 12.5 mm · Manufacturer: swiing® revival parts · Material: Plastic · Color: black · Mounting type: Plug connection · Number of fixing points: 2 pcs · Total length: 74 mm · Hole spacing: 63 mm

GPO control bearing set M26x1 | Puch

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Color: silver · Bearing type: Bearing ring · Thread type: MF26x1 (fine pitch thread) · Ø mounting frame: 31 mm · Ø inside: 26.8 mm · Ø outside: 41 mm

GPO chain tensioner | Puch Maxi S

Manufacturer: GPO · Material: Plastic · Material: Steel · Surface: galvanized (blue) · Color: black · Color: silver · Thread type: M6x1 (standard thread) · Number of teeth: 10 pcs · Ø outside sprocket: 36 mm · Number of fixing points: 1 pcs · Total length: 175 mm

GPO sprocket 45 teeth black | Puch Maxi, Puch X30 NG-2AH

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: GPO · Material: Steel · Surface: powder-coated · Color: black · Number of teeth: 45 pcs · Ø inside: 94 mm · Ø bolt circle: 105.5 mm · Number of fixing points: 6 pcs · Thickness: 4.5 mm · Ø mounting hole: 6.7 mm · Hole spacing: 36.5 mm · Hole spacing 2: 68 mm · Cranking (offset): 8 mm

EBR fork reinforced black | Puch

Manufacturer: EWC · Material: Steel · Surface: chrome-plated · Color: Chrome · Color: black · Thread type: MF26x1 (fine pitch thread) · Adjustable: No · Spar end distance (center-center): 140 mm · Ø outer head tube: 26 mm · Ø head tube inside: 22 mm · Ø spars: 28 mm · Head tube length: 180 mm · Thread length: 57 mm · Fork bridge - center wheel axle: 381 mm · Total length: 580 mm · Distance brake cam to wheel axle center-center: 40 mm

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Thread type: MF12x1 (fine pitch thread) · Mounting type: Union nut · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

GPO cable duct black | Puch Maxi, Supermaxi

Width: 58 mm · Height: 22 mm · Manufacturer: GPO · Material: Plastic · Color: black · Number of fixing points: 2 pcs · Total length: 320 mm · Ø mounting hole: 5.3 mm

swiing® revival side protection screw set black | Puch Maxi S

Drive: Slot · Drive: Triangular head · Manufacturer: swiing® revival parts · Material: Plastic · Material: Steel · Surface: galvanized (blue) · Surface: raw · Color: silver · Thread type: M5x0.8 (standard thread) · Thread length: 35 mm · Thread length: 50 mm · Total length: 47 mm · Total length: 60 mm

swiing® revival 17" front fender primed | Puch Maxi S, N

Material: Steel · Color: black · Manufacturer: swiing® revival parts · Surface: primed · Folding the ends: closed folded · Shape of the mudguard: angular · Total length over ends: 565 mm · Mounting type: Nuts & bolts · Scope: 740 mm · Wide mudguard profile: 82 mm · Height of mudguard profile: 35 mm · Total height from support surface to top edge: 200 mm · Wheel size: 17 "

GPO mudguard strut front 17" black

Manufacturer: GPO · Material: Steel · Surface: varnished · Color: black · Mounting type: Nuts & bolts · Distance mudguard - center hole: 300 mm · Number of fixing points: 4 pcs · Ø mounting hole: 7 mm · Ø mounting hole: 12.5 mm · Total length: 305 mm · Wheel size: 17 "
