Polini 2-folding diaphragm insert

Dell'Orto 16/16 SHA carburetor hand choke

Carburetor type: SHA · Nominal diameter: 16 mm · Manufacturer: Dell'Orto · Camouflaged: No · Component group Carburetor: Carburetor complete · Material: Aluminum · Ø without reducing sleeve: 21 mm · Height: 111 mm · Ø Inside entrance: 16 mm · Ø Output inside: 16 mm · Color: black · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Ø Internal connection: 19 mm · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Total length: 82 mm · Mixed oil connection: No · Vacuum connection: No · Width: 72 mm · Choke control: Hand choke · Mounting type: Plug connection clamped · Nozzle thread: M5x0.8 (standard thread) · Area of application: Tuning · Nozzle size: 82

DMP 2 hinged membrane insert

Manufacturer: DMP · Number of flaps: 2 pcs · Membrane material: Spring steel · Number of fixing points: 4 pcs · Ø mounting hole: 5.8 mm · Area of application: Tuning · Mounting type: Screws · Hole pattern [mm]: 39 x 36/32 mm

Malossi 2-folding diaphragm insert carbonite | Puch / Tomos / Peugeot

Width: 42.2 mm · Width: 46.2 mm · Thickness: 3.3 mm · Manufacturer: Malossi · Number of flaps: 1 pcs · Thick membrane platelets: 0.35 mm · Number of fixing points: 4 pcs · Ø mounting hole: 5.65 mm · Area of application: Tuning · Total length: 50.4 mm · Mounting type: Screws · Hole pattern [mm]: 39 x 36/32 mm

Polini gasket diaphragm

Manufacturer: Polini · Place of use: Admission · Ø cylinder: 45 mm

Polini intake system 4-folding diaphragm SHA | Puch

Ø inside: 15 mm · Ø outside: 19 mm · Manufacturer: Polini · Material: Aluminum · Number of flaps: 4 pcs · Area of application: Tuning · Mounting type: Screws

Malossi gasket set 4-folding diaphragm | Puch, Peugeot

Manufacturer: Malossi · Material: Sealing paper · Mounting type: Screws · Number of fixing points: 4 pcs · Area of application: Tuning

swiing® revival Stud Bolt, Inlet/Outlet M6x30 (Grade 10.9)

Manufacturer: swiing® revival parts · Material: Steel · Diameter: 5.95 mm · Surface: galvanized (blue) · Nominal diameter (thread): 6 mm · Total length: 30 mm · Thread length: 12 mm · Thread type: M6x1 (standard thread) · Strength class: 10.9

Motorex Automatic Motor Oil (ATF) 450 ml

Temperature resistance (min.): -45 - 200 °C · Manufacturer: Motorex · Contents: 450 ml · Gearbox type: Automatic machine · Area of application: Gearbox lubrication with clutch · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Nipple shape: Ball · Ø nipple: 3.5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Ø Stranded wire: 1.2 mm · Number of components: 1 pcs · Cable length: 1650 mm

swiing® revival nozzle set M5 (50 - 70) Dell'Orto SHA, PHBG

Carburetor type: PHBG · Carburetor type: SHA · Carburetor type: SHA (Piaggio) · Manufacturer: swiing® revival parts · Component group Carburetor: Spraying · Material: Brass · Quantity: 10 pcs · Nozzle type: Main nozzle · Drive: Slot · Total length: 8 mm · Nozzle thread: M5x0.8 (standard thread) · Nozzle size: 50 · Nozzle size: 52 · Nozzle size: 55 · Nozzle size: 58 · Nozzle size: 60 · Nozzle size: 62 · Nozzle size: 64 · Nozzle size: 66 · Nozzle size: 68 · Nozzle size: 70

Polini 2-folding diaphragm Peugeot 103

Manufacturer: Polini · Number of flaps: 2 pcs · Hole pattern [mm]: 39 x 36/32 mm · Thickness: 2 mm · Ø mounting hole: 5.3 mm · Mounting type: Screws · Number of fixing points: 4 pcs · Area of application: Tuning

Polini 2-folding diaphragm Puch

Manufacturer: Polini · Number of flaps: 2 pcs · Hole pattern [mm]: 39 x 36/32 mm · Thickness: 2 mm · Ø mounting hole: 5.3 mm · Mounting type: Screws · Number of fixing points: 4 pcs · Area of application: Tuning

Polini 2-folding diaphragm | Tomos

Manufacturer: Polini · Mounting type: Screws · Number of fixing points: 4 pcs · Area of application: Tuning · Number of flaps: 2 pcs · Hole pattern [mm]: 39 x 36/32 mm · Tomos OEM number: 222238

GPO 14 mm intake manifold (camouflaged) | Tomos

Ø inside: 14.5 mm · Manufacturer: GPO · Material: Aluminum · Camouflaged: Yes · Number of fixing points: 4 pcs · Area of application: Tuning · Ø External connection: 18 mm · Mounting type: Screws
