swiing® revival bearings & shaft seals Motor | Cilo

Motorex engine oil (gear oil) manual 450 ml

Manufacturer: Motorex · Viscosity (SAE): 80W · Oil type: GL4 · Contents: 450 ml · Gearbox type: Foot control · Gearbox type: Manual gearshift · Temperature resistance (min.): -30 - 220 °C · Area of application: Gearbox lubrication with clutch

swiing® revival sealing kit | Cilo

Manufacturer: swiing® revival parts · Number of components: 16 pcs · Area of application: Standard

swiing® ingenious piston 40 mm | Cilo 502

Nominal diameter: 40 mm · Manufacturer: swiing® ingenious parts · Thick piston ring: 1.65 mm · Ø outside piston (A): 39.93 mm · Compression height (C): 27.9 mm · Curvature (D): 5.1 mm · Total piston height (E): 54 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Ø piston pin (B): 12 mm · Piston ring height: 2 mm · Weight piston kit: 93 g

Barikit connecting rod 85 mm | Cilo 502T

Manufacturer: Barikite · Material: Steel · Surface: copper-coated · Connecting rod length center-center: 85 mm · Ø Connecting rod bolt: 16 mm · Ø lower connecting rod eye outside: 31 mm · Thickness: 11.8 mm · Ø upper connecting rod eye outside: 22 mm · Ø piston pin (B): 12 mm · Ø lower bearing inside: 22 mm · Ø inside upper bearing: 15 mm · Dimension lower bearing: 16/22 x 11.8 mm · Dimension upper bearing: 12/15 x 14.7 mm · Connecting rod pin length: 30 mm · Total length: 111 mm · Area of application: Standard · Area of application: Tuning

swiing® revival locking plate pinion | Cilo 502

Manufacturer: swiing® revival parts · Ø inside: 15 mm · Ø inside: 17 mm · Ø outside: 29.9 mm · Thickness: 0.8 mm

swiing® revival clutch spring new version | Cilo 502

Spring design: Pressure spring · Ø wire: 4 mm · Manufacturer: swiing® revival parts · Ø inside: 26.35 mm · Ø outside: 34.4 mm · Total length: 30 mm

swiing® revival gasket set cylinder 40 mm | Cilo 502

Manufacturer: swiing® revival parts · Area of application: Tuning · Ø cylinder: 40 mm · Ø outlet inside: 28 mm · Hole spacing inlet: 32 mm · Number of components: 4 pcs

swiing tuning cylinder 40 mm | Cilo 502

Nominal diameter: 40 mm · Manufacturer: swiing · Material: Gray cast iron · Camouflaged: Yes · Surface: sandblasted · Area of application: Tuning · Ø piston pin (B): 12 mm · Thread inlet: M6x1 (standard thread) · Outlet type: Union nut · Number of fixing points: 4 pcs

swiing® revival engine revision set | Cilo 502T 2-speed

Manufacturer: SKF · Manufacturer: swiing® revival parts · Area of application: Standard
