Vespa Tuning

Polini Engine Case | Vespa P125X, P150X, PX125, PX150

Manufacturer: Polini · Material: Cast aluminum · Width: 320 mm · Ignition type: Electronic · Height: 345 mm · Total length: 420 mm

Polini Engine Case | Vespa P200E, PX200

Manufacturer: Polini · Material: Cast aluminum · Width: 320 mm · Ignition type: Electronic · Height: 345 mm · Total length: 420 mm

Polini clutch cover | Vespa Largeframe

Manufacturer: Polini · Material: Cast aluminum · Height: 41 mm · Ø inside: 121.8 mm · Number of fixing points: 3 pcs · Ø outside: 139 mm

SIP Ignition Vape Road Classic AC | Vespa P, PX, Cosa, GTR, TS, Sprint V., Rally, Super

Manufacturer: SIP · Material: Cast aluminum · Tension: 12 V · Performance: 110 W · Ø mounting plate: 115.5 mm · Ø Internal flywheel: 87.6 mm · Ø Flywheel outside: 103.7 mm · Number of fixing points: 3 pcs

SIP Ignition Vape Road Classic DC | Vespa P, PX, Cosa, GTR, TS, Sprint V., Rally, Super

Manufacturer: SIP · Material: Cast aluminum · Area of application: Road use · Tension: 12 V · Performance: 110 W · Ø mounting plate: 115.5 mm · Ø Internal flywheel: 87.6 mm · Ø Flywheel outside: 103.7 mm · Number of fixing points: 3 pcs

VMC air filter "Venturi" | Vespa Largeframe

Manufacturer: VMC · Material: Cast aluminum · Area of application: Tuning · Filter type: Foam · Width: 125 mm · Mounting type: Screws · Height: 87 mm · Total length: 232 mm · Ø outside: 55 mm · Camouflaged: No

VMC 63 mm cylinder kit "177 Crono" | Vespa Largeframe

Manufacturer: VMC · Material: Aluminum · Area of application: Tuning · Crankshaft stroke: 60 mm · Displacement: 177 ccm · Ø cylinder neck: 66.75 mm · Ø Outlet outside: 37 mm · Ø outlet inside: 34 mm · Ø piston pin (B): 15 mm · Number of fixing points: 4 pcs · Decompressor: No · Outlet type: straight · Hole spacing outlet: 48 mm · Camouflaged: No

VMC 63 mm cylinder kit "177 Stelvio 2.0" | Vespa Largeframe

Manufacturer: VMC · Material: Aluminum · Area of application: Tuning · Crankshaft stroke: 57 mm · Displacement: 177 ccm · Ø cylinder neck: 66 mm · Ø Outlet outside: 37 mm · Ø outlet inside: 34 mm · Ø piston pin (B): 15 mm · Number of fixing points: 4 pcs · Decompressor: No · Outlet type: straight · Hole spacing outlet: 48 mm · Camouflaged: No

VMC 63 mm cylinder kit "177 Super G 2.0" | Vespa Largeframe

Manufacturer: VMC · Material: Gray cast iron · Area of application: Tuning · Crankshaft stroke: 57 mm · Displacement: 177 ccm · Ø cylinder neck: 66.6 mm · Ø Outlet outside: 37 mm · Ø outlet inside: 34 mm · Ø piston pin (B): 15 mm · Number of fixing points: 4 pcs · Decompressor: No · Outlet type: straight · Hole spacing outlet: 48 mm · Camouflaged: No

VMC 72 mm cylinder kit "244 Explorer" | Vespa P, PX, Cosa, Rally

Manufacturer: VMC · Material: Aluminum · Area of application: Tuning · Crankshaft stroke: 60 mm · Displacement: 244 ccm · Ø cylinder neck: 75.8 mm · Ø Outlet outside: 44.5 mm · Ø outlet inside: 38.5 mm · Ø piston pin (B): 16 mm · Number of fixing points: 4 pcs · Decompressor: No · Outlet type: straight · Hole spacing outlet: 48 mm · Camouflaged: No

Malossi 63 mm Cylinder Kit "MHR 177" | Vespa Large Frame

Manufacturer: Malossi · Material: Aluminum · Area of application: Tuning · Crankshaft stroke: 57 mm · Displacement: 177 ccm · Ø cylinder neck: 67 mm · Ø Outlet outside: 37 mm · Ø outlet inside: 33.9 mm · Ø piston pin (B): 15 mm · Number of fixing points: 4 pcs · Decompressor: No · Outlet type: straight · Hole spacing outlet: 55 mm · Camouflaged: No

Malossi 68.5 mm Cylinder Kit "Sport MK II 210" | Vespa P, PX, Cosa, Rally

Manufacturer: Malossi · Material: Aluminum · Area of application: Tuning · Crankshaft stroke: 57 mm · Displacement: 210 ccm · Ø cylinder neck: 73.2 mm · Ø Outlet outside: 46 mm · Ø outlet inside: 37.8 mm · Ø piston pin (B): 16 mm · Number of fixing points: 4 pcs · Outlet type: straight · Hole spacing outlet: 58 mm · Camouflaged: No

Polini crankshaft "Racing" 57 mm | Vespa PX200, P200, Rally 200, Cosa 200

Manufacturer: Polini · Material: Steel · Cheek type: standard · Area of application: Tuning · Crankshaft stroke: 57 mm · Connecting rod length center-center: 110 mm · Total length of crankpin on clutch side: 58.8 mm · Total length crankpin ignition side: 77.7 mm · Ø crank webs: 97.9 mm · Ø piston pin (B): 16 mm · Thread length: 14.5 mm · Thread length: 15.5 mm · Ø Connecting rod eye: 20 mm · Ø Bearing seat (clutch side): 25 mm · Ø Bearing seat (ignition side): 25 mm · Thread type: MF12x1.25 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Dimension needle bearing: 16x20x20 · Wide crank webs: 39.1 mm · Control time according to O.T: 5 ° · Control time according to O.T: 138 °

Polini crankshaft "Racing" 60 mm long-stroke | Vespa PX200, P200, Rally 200, Cosa 200

Manufacturer: Polini · Material: Steel · Cheek type: standard · Area of application: Racing · Crankshaft stroke: 60 mm · Connecting rod length center-center: 110 mm · Total length of crankpin on clutch side: 58.8 mm · Total length crankpin ignition side: 77.7 mm · Ø crank webs: 97.9 mm · Ø piston pin (B): 16 mm · Thread length: 14.5 mm · Thread length: 15.5 mm · Ø Connecting rod eye: 20 mm · Ø Bearing seat (clutch side): 25 mm · Ø Bearing seat (ignition side): 25 mm · Thread type: MF12x1.25 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Dimension needle bearing: 16x20x20 · Wide crank webs: 39 mm · Control time according to O.T: 5 ° · Control time according to O.T: 138 °

Polini crankshaft "Racing" 57 mm | Vespa PX, P, Cosa, GTR, TS, Sprint V.

Manufacturer: Polini · Material: Steel · Cheek type: standard · Area of application: Tuning · Crankshaft stroke: 57 mm · Connecting rod length center-center: 105 mm · Total length of crankpin on clutch side: 59 mm · Total length crankpin ignition side: 77.35 mm · Ø crank webs: 98 mm · Ø piston pin (B): 15 mm · Thread length: 14.5 mm · Thread length: 15.5 mm · Ø Connecting rod eye: 19 mm · Ø Bearing seat (clutch side): 25 mm · Ø Bearing seat (ignition side): 25 mm · Thread type: MF12x1.25 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Dimension needle bearing: 15x19x20 · Wide crank webs: 39 mm · Control time according to O.T: 5 ° · Control time according to O.T: 138 °

Polini crankshaft "Racing" 60 mm long-stroke | Vespa PX, P, Cosa, GTR, TS, Sprint V.

Manufacturer: Polini · Material: Steel · Cheek type: standard · Area of application: Racing · Crankshaft stroke: 60 mm · Connecting rod length center-center: 105 mm · Total length of crankpin on clutch side: 59 mm · Total length crankpin ignition side: 77.35 mm · Ø crank webs: 98 mm · Ø piston pin (B): 15 mm · Thread length: 14.5 mm · Thread length: 15.5 mm · Ø Connecting rod eye: 19 mm · Ø Bearing seat (clutch side): 25 mm · Ø Bearing seat (ignition side): 25 mm · Thread type: MF12x1.25 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Dimension needle bearing: 15x19x20 · Wide crank webs: 39 mm · Control time according to O.T: 5 ° · Control time according to O.T: 138 °

Mazzucchelli crankshaft "Sport" | Vespa PX, P, Cosa, GTR, TS, Sprint V.

Manufacturer: Mazzucchelli · Material: Steel · Cheek type: standard · Area of application: Standard · Crankshaft stroke: 57 mm · Connecting rod length center-center: 105 mm · Total length of crankpin on clutch side: 58 mm · Total length crankpin ignition side: 76 mm · Ø crank webs: 98 mm · Ø piston pin (B): 15 mm · Ø Connecting rod eye: 19 mm · Ø Bearing seat (clutch side): 25 mm · Ø Bearing seat (ignition side): 25 mm · Thread type: MF12x1.25 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Dimension needle bearing: 15x19x20 · Wide crank webs: 38.9 mm · Piaggio OEM number: 131121 · Piaggio OEM number: 133154

Polini exhaust "original" | Vespa P, PX, Cosa 125/150

Manufacturer: Polini · Material: Steel · Color: black-matt · Surface: varnished · Ø Internal connection: 37 mm

Polini exhaust "original" | Vespa PX200, P200, Rally 200

Manufacturer: Polini · Material: Steel · Color: black-matt · Surface: varnished · Ø Internal connection: 45 mm
